Hanturbo Technology (Zhejiang) Co., Ltd. is one of the leading manufacturers and suppliers of food-grade co2 plant in China. We specialize in providing high quality custom service with competitive price. If you're going to buy discount food-grade co2 plant, welcome to get quotation from our factory.
The food-grade CO2 plant is a high-purity carbon dioxide preparation and purification system specially designed for the food and beverage industry. It utilizes advanced pressure swing adsorption and low-temperature distillation coupling technology to purify industrial-grade carbon dioxide to over 99.99% food-grade standard. The unit operates stably, has low energy consumption, and high automation, making it an ideal choice for the production of carbonated drinks, food preservation, beer brewing, and other fields, helping enterprises to achieve independent supply of high-quality gas.
Product Details
Product Specifications
|
Specification Items |
Technical Parameters |
|
Processing Capacity |
50~5000 Nm³/h (Customizable as per requirement) |
|
Product Purity |
CO₂ ≥ 99.99%, Water ≤ 20ppm, Oil ≤ 5ppm |
|
Work pressure |
0.3~2.5 MPa (adjustable) |
|
Operating temperature |
-40℃~+50℃ |
|
Control method |
PLC full automatic control, supports remote monitoring |
|
Energy consumption indicators |
≤ 0.35 kWh/Nm³ (subject to raw gas conditions) |
|
Occupied area |
15~200 m² (configuration according to model) |
|
Meets Standards |
GB 1886.228-2016 |
Core Function and Technical Principles
The core of the food-grade CO2 plant lies in the multi-stage purification process: the raw gas is first passed through a desulfurization tower to remove sulfur compounds, then enters the drying system for deep dehydration, followed by activated carbon adsorption to remove odors and organic matter, and finally separated and purified by a low-temperature distillation tower to produce high-purity carbon dioxide that meets international food-grade standards. The entire process is equipped with an on-line analyzer to monitor purity, moisture, and impurity content in real-time, ensuring that each batch of product meets food safety requirements.
The unit adopts a modular design, which can be flexibly configured with pretreatment units according to the existing gas source conditions of customers (such as ammonia synthesis tail gas, fermentation gas, lime kiln gas, etc.), to maximize the use of existing resources and reduce raw material procurement costs.
Product Advantages
(1)Energy-saving and Cost-effective Operation Optimized heat exchange network design, with a system heat recovery efficiency of over 85%; intelligent load regulation function can automatically adjust production capacity according to gas demand, avoiding energy waste; the comprehensive operating cost is reduced by 30% to 50% compared to purchasing liquid CO₂.
(2)Intelligent Control, Easy to Operate Fully automated PLC control system, one-button start and stop, with fault self-diagnosis; equipped with HMI human-machine interface, operation parameters, energy consumption data, and maintenance reminders are clearly visible, significantly reducing the skill requirements for operators.
(3)Compact Design, Easy Installation Skid-mounted structure design, complete with overall debugging before delivery; only need to connect the pipeline at the site for quick production, short construction period, suitable for new projects or existing production line transformation.
Customer Concerns Answer
Q: What are the sources of the raw gas?
A: Suitable for various gas sources such as synthetic ammonia desulfurization tail gas, alcohol fermentation gas, natural gas combustion gas, lime kiln gas, etc. The technical team can provide free gas source evaluation services.
Q: How is after-sales service guaranteed?
A: Offer 12 months of warranty period and lifetime technical support.
