Project Overview



Our company's KDON-5200/12000 model air separation unit, which was specially designed to the 45,000 ton/year high-purity nickel project of Huake Nickel Industry Co., LTD in Indonesia.

All product parameters have met or even exceeded the performance indicators stipulated in the Contract, and the construction period and quality have both met the requirements and standards.

The production process of this air separation unit follows the advanced external compression technology. The main equipment is all from domestic and international high-end facilities. The production facility has many advantages such as high safety level, reliable operation, strong operability, and low energy consumption.

page-750-500
page-750-500
page-750-500



Technical Parameters of Air Separation Unit



Product Name

Output (Nm³/h)

Purity

Notes

Oxygen

5,250

≥ 99.65% O2

External compression

Liquid Oxygen

110 L/h

≥ 99.65% O2

To storage tank

Nitrogen

12,300

≥ 99.995% N2

≤ 5PPm O2

External compression

Liquid Nitrogen

110 L/h

≥ 99.995% N2

≤ 5PPm O2

To storage tank
